Model:FT-SQ5
Brand:fengtu
1.Product Introduction of Handheld Weather Meter
It is a handheld instrument for measuring wind speed, wind direction, atmospheric temperature, relative humidity and atmospheric pressure, integrating a number of meteorological elements in one.Handheld Weather Meter is a portable weather observation instrument that is easy to carry, simple to operate, and integrates multiple meteorological elements. The system uses precision sensors and smart chips to accurately measure five meteorological elements: wind direction, wind speed, atmospheric pressure, temperature, and humidity. The built-in large-capacity FLASH storage chip can store at least one year of meteorological data; the universal USB communication interface can be connected to a U disk to export data, which is convenient for users to further process and analyze meteorological data.
Handheld Weather Meter can be widely used in meteorology, environmental protection, airports, agriculture and forestry, hydrology, military, warehousing, scientific research and other fields.
2. Features of Handheld Weather Meter
2.1-inch LCD screen displays temperature, humidity, wind speed, and air pressure;
Special wind direction dial (16 directions) and pointer are used to indicate real-time wind direction;
Large-capacity data storage, can store up to 40,000 meteorological data (data recording interval can be set between 1 and 60 minutes);
Universal USB communication interface, convenient for USB data download;
Only three AA batteries are needed for power supply; low power consumption design, long standby time;
The structural design is scientific and reasonable, and it is easy to carry.
3. Handheld Weather Meter Technical Parameters
Meteorological parameters | Measuring features | Measuring range | Accuracy | Resolution | unit |
Wind speed | 0~30 | ±0.3 | 0.01 | m/s | |
wind direction | 16 directions | ±1 azimuth | 1 position | position | |
Atmospheric temperature | -40~85 | ±0.3 | 0.01 | ℃ | |
Relative humidity | 0~100% | ±3% | 0.01 | %RH | |
Atmospheric pressure | 30~110 | ±0.02 (relative) | 0.01 | KPa | |
power supply | AA batteries (4 pieces) | ||||
communication | USB | ||||
storage | 40,000 records | ||||
Host size | 160mm×70mm×28mm | ||||
Overall size | 405mm×100mm×100mm | ||||
weight | About 0.5Kg | ||||
working environment | -20℃~80℃; 5%RH~95%RH |
4. Precautions for using Handheld Weather Meter
1. It is recommended to clean up the data storage every time you need to record the time when starting the machine to prevent the large amount of data when exporting the currently required data, which will take too long.
2. It is recommended to export the data content in the weather station in time after use.
3. Please read this manual carefully before use to ensure that the sensor is inserted into the corresponding sensor interface and the battery is in the correct direction;
4. When the instrument shows that the battery power is low, please replace the battery in time to prevent battery leakage from damaging the instrument;
5. Prevent chemical reagents, oil, dust, etc. from directly damaging the sensor. Do not use it for a long time in an environment with condensation or extreme temperature. Do not subject it to cold or hot shock.
6. The instrument is a precision device. Please do not disassemble it by yourself during use to avoid damaging the product.
7. Please keep the calibration certificate and certificate of conformity and return them together with the product when repairing.
